MDT SCN-BWM63.02 Motion Detector/Automatic Switch 63

The MDT Motion Detector / Automatic Switch with light sensor detects the smallest movements using 2 pyro detectors and a high-resolution lens. Two separate lighting channels, one HVAC channel and one channel for room monitoring can be configured. The room brightness is measured by the integrated light sensor and made available as an object. The version with temperature sensor and two sensor buttons (SCN-BWM63T.x2) is an all-rounder if you have many corridors and rooms.The MDT Motion Detector 63 fits into the switch lines of leading manufacturers, such as:Busch-Jaeger future linear, solo, carat, Busch-axcent
Busch-Jaeger future linear, solo, carat, Busch-axcent Fits 63 mm systems / ranges Motion detector with 2 pyro sensors and light sensor Two freely programmable sensor keys (SCN-BWMxxT.G2 only) Temperature sensor (SCN-BWMxxT.G2 only) Motion detection angle H 180° / V 15°, coverage 6 - 10 m Ø Suitable for pets up to 12 kg Sensitivity separately adjustable for day / night / presence Detects the direction of movement 2 light channels, 1 channel for HVAC and alarm Short-term presence to reduce follow-up time Master / slave function, scenes and logic functions Integrated white LED night light Day / night function, orientation light function Lock and forced guidance function External push-button input for automatic and manual operation Recommended installation height: 1.05 - 1.20 m Integrated bus coupling unit Production in Germany, certified according to ISO 9001 3 year warranty
